Cable for DeviceNet and CANopen RSC RKC 572-2M
Brand: TURCK
Code: U0323
- Network protocol
- DeviceNet
- Cable length (m)
- 2
- Application
- Data
- Design
- Extension Cable
- Connector A
- Male, M12 × 1, Straight, A-coded
- Number of pins
- 5
- Coupling nut/screw material A
- Brass
- Connector B
- Female, M12 × 1, Straight, A-coded
- Number of Pins
- 5
- Coupling nut/screw material B
- Brass
- Voltage (V)
- 250
- Current (A)
- 4
- Cable quality
- PVC
- Cable color
- Gray
- Special features
- Shielded
- Approvals
- FM Div.2, CSA PA, UL 2238, CSA C22.2 No. 182.3, CE, UKCA, RoHS
- Ambient temperature min. (°C)
- 5
- Ambient temperature max. (°C)
- 80
- Number of Conductors
- 4
