E21239 - efector200-FIXTURE FOR FINE ADJUSTMENT
Brand: IFM Electronic
Code: E21239
- For an easy alignment of photoelectric sensors
- Easy, quick and inexpensive fixing
- Robust design for use in harsh industrial environments
- For free-standing mounting
- Each sensor position possible due to free movement in all directions
Application
| Installation | free-standing mounting; (with fine adjustment) |
|---|
Mechanical data
| Weight [g] | 38.5 |
|---|---|
| Type of mounting | free-standing |
| Dimensions [mm] | 57.3 x 12 x 28 |
| Materials | fixture: stainless steel; Spring: spring steel; screws: stainless steel |
Accessories
| Items supplied |
|
|---|
Remarks
| Pack quantity | 1 pcs. |
|---|
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — E21239-00 — 27.08.2021 —
