E40434 - FLOW ADAPT
Brand: IFM Electronic
Code: E40434
- Reliable detection of small flow rates
- Easy installation of the flow sensor via adapter
- Very high pressure rating
- Robust stainless steel design for use in harsh industrial environments
- Suitable for liquids and gases
Application
| Application | for industrial applications |
|---|---|
| Installation | via internal G1/8A male thread, any mounting position; (SA5) |
| Medium temperature [°C] | 0...80 |
| Pressure rating [bar] | 100 |
Measuring/setting range
| Flow range [ml/min] | 2...150 |
|---|
Tests / approvals
| Pressure Equipment Directive EAC | The adapter is intended for use in devices, machines and installations that do not fall under the categories of the technical rule TR CU 032/2013. |
|---|
Mechanical data
| Weight [g] | 212.7 |
|---|---|
| Materials | stainless steel (1.4404 / 316L) |
| Sensor connection | M12 x 1 |
| Process connection | G 1/8 |
Accessories
| Items supplied |
| ||
|---|---|---|---|
| Accessories (optional) |
|
Remarks
| Remarks |
| |
|---|---|---|
| Pack quantity | 1 pcs. |
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — E40434-00 — 25.10.2016 —
