FOUNDATION fieldbus Flanschanschluss RSFV 49-0.3M/14.5/C1117
Brand: TURCK
Code: U7834
- Network protocol
- FOUNDATION fieldbus
- Application
- Data
- Design
- Connection Cable
- Connector A
- Male, 7/8″-16 UN, Straight
- Number of pins
- 4
- Receptacle housing material A
- Stainless Steel
- Screw-in thread
- 1/2″-14 NPT
- Voltage (V)
- 600
- Current (A)
- 9
- Approvals
- CE, RoHS
- Ambient temperature min. (°C)
- -40
- Ambient temperature max. (°C)
- 105
- Core cross-section (mm²)
- 0.8
- Connection technology signal
- 7/8”
- Connection mode
- Wire connection
