Terminal resistor ICZ-TR-V1-110R
Brand: Pepperl+Fuchs
Code: ICZ-TR-V1-110R
Terminal resistor for CC-Link
Datasheet excerpt: Technical data of ICZ-TR-V1-110R
| Product Description |
|---|
| Terminal resistor for CC-Link |
| General specifications | ||
|---|---|---|
| Number of pins | 4 | |
| Electrical specifications | ||
| Rated voltage | 24 V | |
| Rated current | 20 mA at 40 °C | |
| Resistor | R = 110 Ω | |
| Directive conformity | ||
| RoHS | ||
| Directive 2011/65/EU (RoHS) | IEC/EN 63000 | |
| Ambient conditions | ||
| Ambient temperature | -25... 90 °C (-13... 194 °F) | |
| Mechanical specifications | ||
| Degree of protection | IP65 / IP67/ IP69K | |
| Connection | 4-pin M12 connector, for CC-Link | |
| Material | ||
| Contacts | CuZn | |
| Contact surface | Ni/Au | |
| Body | TPU, black | |
Classifications
| System | Classcode |
|---|---|
| ECLASS 13.0 | 27260190 |
| ECLASS 12.0 | 19070403 |
| ECLASS 11.0 | 19070403 |
| ECLASS 10.0.1 | 19070403 |
| ECLASS 9.0 | 27279090 |
| ECLASS 8.0 | 27279290 |
| ECLASS 5.1 | 27279201 |
| ETIM 9.0 | EC003015 |
| ETIM 8.0 | EC003015 |
| ETIM 7.0 | EC003015 |
| ETIM 6.0 | EC003015 |
| ETIM 5.0 | EC002585 |
| UNSPSC 12.1 | 31251501 |
