IM0055 - efector100-IMC2020BARKA/LS-100AK RT
Brand: IFM Electronic
Code: IM0055
- Long sensing range for use in conveying
- With combined AC/DC output and two-wire technology
- Robust housing for use in harsh industrial environments
- Five positions of the sensing face selectable
- LED display to check operation, switching status and function
Product characteristics
| Output function | normally open |
|---|---|
| Sensing range [mm] | 20 |
| Housing | rectangular |
| Dimensions [mm] | 40 x 40 x 66 |
Electrical data
| Frequency AC [Hz] | 47...63 |
|---|---|
| Operating voltage [V] | 20...140 AC / 10...140 DC |
| Protection class | I |
| Reverse polarity protection | yes |
Outputs
| Output function | normally open |
|---|---|
| Max. voltage drop switching output DC [V] | 5.5 |
| Max. voltage drop switching output AC [V] | 5.5 |
| Minimum load current [mA] | 5.5 |
| Max. leakage current [mA] | 1.7 (140 V AC/DC) |
| Permanent current rating of switching output AC [mA] | 450 |
| Permanent current rating of switching output DC [mA] | 450 |
| Short-time current rating of switching output [mA] | 2200; (20 ms / 0,5 Hz) |
| Switching frequency AC [Hz] | 25 |
| Switching frequency DC [Hz] | 100 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
Detection zone
| Sensing range [mm] | 20 |
|---|---|
| Real sensing range Sr [mm] | 20 ± 10 % |
| Operating distance [mm] | 0...16.2 |
Accuracy / deviations
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminium: 0.4 / copper: 0.3 |
|---|---|
| Hysteresis [% of Sr] | 3...20 |
| Switch point drift [% of Sr] | -10...10 |
Operating conditions
| Ambient temperature [°C] | -25...70 |
|---|---|
| Protection | IP 67 |
Tests / approvals
| EMC |
| ||||||||
|---|---|---|---|---|---|---|---|---|---|
| MTTF [years] | 351 | ||||||||
| UL approval |
|
Mechanical data
| Weight [g] | 259.5 |
|---|---|
| Housing | rectangular |
| Mounting | flush mountable |
| Dimensions [mm] | 40 x 40 x 66 |
| Materials | housing: PPE; sensing face: PPE orange; end cap: diecast zinc; clamp: diecast zinc black; screw: steel galvanised |
Displays / operating elements
| Display |
|
|---|
Remarks
| Remarks |
| |
|---|---|---|
| Pack quantity | 1 pcs. |
Electrical connection - plug
| Connector: 1 x 1/2"; coding: C; Locking: brass, white bronze coated |
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — IM0055-00 — 13.04.2023 —
