RFID read/write device IPH-F90A-V1
Brand: Pepperl+Fuchs
Code: IPH-F90A-V1
LF RFID read/write device for IDENTControl
Datasheet excerpt: Technical data of IPH-F90A-V1
| Product Description |
|---|
| LF RFID read/write device for IDENTControl |
| General specifications | ||
|---|---|---|
| Operating frequency | 125 kHz | |
| Transfer rate | 2 kBit/s | |
| Sensing range | ||
| Read distance | 3... 90 mm (with transponder IPC03-50P at 25°C) | |
| Write distance | 3... 80 mm (with transponder IPC03-50P at 25°C) | |
| Width | max. 140 mm | |
| UL File Number | E87056 | |
| MTBF | 350 a (Operation at +40 °C) | |
| Indicators/operating means | ||
| LED green/yellow | green: power on green flashing: read/write attempt performed yellow: data carrier detected | |
| Electrical specifications | ||
| Power consumption | ≤ 1.2 W | |
| Supply | from the IDENTControl | |
| Mag. Field strength | < 27.3 dBµA/m at 10 m | |
| Directive conformity | ||
| Radio equipment | ||
| Directive 2014/53/EU | EN 301489-1 EN 301489-3 EN 300330 EN 62368-1 EN 50364 | |
| RoHS | ||
| Directive 2011/65/EU (RoHS) | IEC/EN 63000 | |
| Standard conformity | ||
| Degree of protection | EN 60529 | |
| RFID | ISO/IEC 18000-2 | |
| Ambient conditions | ||
| Ambient temperature | -25... 55 °C (-13... 131 °F) | |
| Storage temperature | -40... 55 °C (-40... 131 °F) | |
| Mechanical specifications | ||
| Housing length | 144.5 mm | |
| Housing width | 43.5 mm | |
| Housing height | 21 mm | |
| Degree of protection | IP67 | |
| Connection | connector M12 x 1 | |
| Material | ||
| Housing | ABS | |
| Encapsulation compound | WEVO 403FL/300 | |
| Installation | ||
| Distance between two heads | Multiplex on: ≥ 100 mm Multiplex off: ≥ 550 mm | |
| Mass | approx. 180 g | |
Classifications
| System | Classcode |
|---|---|
| ECLASS 13.0 | 27280401 |
| ECLASS 12.0 | 27280401 |
| ECLASS 11.0 | 27280401 |
| ECLASS 10.0.1 | 27280401 |
| ECLASS 9.0 | 27280401 |
| ECLASS 8.0 | 27280401 |
| ECLASS 5.1 | 27280401 |
| ETIM 9.0 | EC002998 |
| ETIM 8.0 | EC002998 |
| ETIM 7.0 | EC002998 |
| ETIM 6.0 | EC002998 |
| ETIM 5.0 | EC002998 |
| UNSPSC 12.1 | 43211710 |
