Mounting aid MH-EXG-08
Brand: Pepperl+Fuchs
Code: MH-EXG-08
Quick mounting bracket with dead stop
Datasheet excerpt: Technical data of MH-EXG-08
| Product Description |
|---|
| Quick mounting bracket with dead stop |
| Ambient conditions | ||
|---|---|---|
| Ambient temperature | -40... 90 °C (-40... 194 °F) | |
| Mechanical specifications | ||
| Length | 31 mm thread length of sensor min. 31 mm | |
| Diameter | sensor min. 7.8 mm sensor max. 8 mm | |
| Material | brass, nickel-plated free of paint wetting interfering substances | |
| Screwed connection | SW = 17 mm | |
| Dimensions | M12 x 1 external thread | |
| Tightening torque | 12 Nm | |
| General information | ||
| Note | Attention: Sensor shape dependent, it will be fixed up to 0.7 mm in back-flush position. | |
Classifications
| System | Classcode |
|---|---|
| ECLASS 13.0 | 27273701 |
| ECLASS 12.0 | 27273701 |
| ECLASS 11.0 | 27273701 |
| ECLASS 10.0.1 | 27273701 |
| ECLASS 9.0 | 27273701 |
| ECLASS 8.0 | 27279202 |
| ECLASS 5.1 | 27279202 |
| ETIM 9.0 | EC003015 |
| ETIM 8.0 | EC003015 |
| ETIM 7.0 | EC003015 |
| ETIM 6.0 | EC003015 |
| ETIM 5.0 | EC003015 |
| UNSPSC 12.1 | 31162301 |
