OJ5065 Through-beam sensor transmitter OJS-OOKG/FO/0,15M/US

Code: OJ5065

Particularly compact housing for use where space is restricted
Very long range
Simple alignment due to visible red light
Easy mounting by clipping onto a mounting base

Product characteristics

Type of light	red light
Housing	rectangular

Application

Special feature	Gold-plated contacts
Function principle	Through-beam sensor

Electrical data

Operating voltage [V]	10...30 DC
Current consumption [mA]	< 19
Protection class	III
Reverse polarity protection	yes
Type of light	red light
Wave length [nm]	660

Outputs

Overload protection	yes

Detection zone

Transmitter / receiver	transmitter
Range [m]	< 10
Max. light spot diameter [mm]	1000
Light spot dimensions refer to	at maximum range

Operating conditions

Ambient temperature [°C]	-25...60
Protection	IP 67

Tests / approvals

EMC

EN 60947-5-2

MTTF [years]

1773

Mechanical data

Weight [g]

52.05

Housing

rectangular

Dimensions [mm]

35 x 24 x 11

Materials

housing: ABS; fixture: diecast zinc; LED window: SEPS; pushbutton: SEPS

Lens material

glass

Lens alignment

front lens

Displays / operating elements

Display

operation

1 x LED, green

Accessories

Items supplied

Basic clip: 1, E20964

screws: 2 x M3 x 16

spring washers: 2

Nuts: 2

Remarks

operating voltage "supply class 2" according to cULus

Pack quantity

1 pcs.

Electrical connection

Connection	Cable: 0.15 m, PVC
Connection	Connector: 1 x M12; coding: A; Moulded body: Hytrel 8068; Locking: stainless steel (1.4404 / 316L); Contacts: gold-plated

ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — OJ5065-01 — 13.04.2023 —
