PROFIBUS-PA Flanschanschluss RSFV 48-0.3M/M20/C1117
Brand: TURCK
Code: U5218-144
- Network protocol
- PROFIBUS-PA
- Application
- Data
- Design
- Connection Cable
- Connector A
- Male, 7/8″-16 UN, Straight
- Number of pins
- 4
- Receptacle housing material A
- Stainless Steel
- Screw-in thread
- M20 × 1.5
- Voltage (V)
- 600
- Current (A)
- 9
- Approvals
- CE, RoHS
- Ambient temperature min. (°C)
- -40
- Ambient temperature max. (°C)
- 105
- Core cross-section (mm²)
- 0.8
- Connection technology signal
- 7/8”
- Connection mode
- Wire connection
