Connecting cable, shielded V19-G-0,2M-PUR-ABG-V19-Y
Brand: Pepperl+Fuchs
Code: V19-G-0,2M-PUR-ABG-V19-Y
Connecting cable, M12 to M12, 8-pin, shielded, PUR cable
Datasheet excerpt: Technical data of V19-G-0,2M-PUR-ABG-V19-Y
| Product Description |
|---|
| Connecting cable, M12 to M12, 8-pin, shielded, PUR cable |
| General specifications | ||
|---|---|---|
| Number of pins | 8 + shield | |
| Connection 1 | socket | |
| Construction type 1 | straight | |
| Threading 1 | M12 | |
| Connection 2 | Male connector | |
| Construction type 2 | straight | |
| Threading 2 | M12 | |
| Electrical specifications | ||
| Operating voltage | max. 30 V AC/DC | |
| Operating current | max. 2 A | |
| Volume resistance | < 5 mΩ | |
| Ambient conditions | ||
| Ambient temperature | -25... 80 °C (-13... 176 °F) | |
| Pollution degree | 3 | |
| Mechanical specifications | ||
| Material | ||
| Contacts | CuZn | |
| Contact surface | Ni/Au | |
| Body | TPU, black Zinc die-casting, nickel-plated | |
| Cable | PUR | |
| Slotted nut | Diecast zinc | |
| Core insolation | PP | |
| Cable | extra-fine wire, flexible | |
| Sheath diameter | ∅5.9 mm | |
| Bending radius | > 10 x cable diameter, moving | |
| Color | black | |
| Cores | 8 x 0.25 mm2 | |
| Conductor construction | 32 x 0.1 mm ∅ | |
| Shield | grid covering 85 % | |
| Length | 20 cm | |
Classifications
| System | Classcode |
|---|---|
| ECLASS 13.0 | 27060311 |
| ECLASS 12.0 | 27060311 |
| ECLASS 11.0 | 27060311 |
| ECLASS 10.0.1 | 27060311 |
| ECLASS 9.0 | 27060311 |
| ECLASS 8.0 | 27279218 |
| ECLASS 5.1 | 27279201 |
| ETIM 9.0 | EC001855 |
| ETIM 8.0 | EC001855 |
| ETIM 7.0 | EC001855 |
| ETIM 6.0 | EC001855 |
| ETIM 5.0 | EC002585 |
| UNSPSC 12.1 | 31251501 |
