Distributor VAZ-CHAIN-BU/BN70MM/1,0-25
Brand: Pepperl+Fuchs
Code: VAZ-CHAIN-BU/BN70MM/1,0-25
25-point wiring link for control cabinet modules with screw terminals
Datasheet excerpt: Technical data of VAZ-CHAIN-BU/BN70MM/1,0-25
| Product Description |
|---|
| 25-point wiring link for control cabinet modules with screw terminals |
| General specifications | ||
|---|---|---|
| UL File Number | E223176 | |
| Electrical specifications | ||
| Nominal voltage | 48 V | |
| Current loading capacity | 8 A at 40 °C DIN VDE 0298 Part 4 HD 516/VDE 0298-300 | |
| Ambient conditions | ||
| Ambient temperature | -30... 80 °C (-22... 176 °F) fixed | |
| Mechanical specifications | ||
| Core cross section | Fine-stranded copper 1 mm2 | |
| Bending radius | Moving: 4 x external diameter Fixed: 2 x external diameter | |
| Material | ||
| Core insulation | PVC | |
| Cable | H05V-K, rated voltage 300/500 V | |
| Color | brown, blue | |
| Connection possibilities | Suitable for screw terminals | |
| Cable length | 25 x 7 cm + 1 m | |
| Flammability | ||
| Cable | Flame-retardant as per IEC 60332-1-2 | |
Classifications
| System | Classcode |
|---|---|
| ECLASS 13.0 | 27279090 |
| ECLASS 12.0 | 27279090 |
| ECLASS 11.0 | 27279090 |
| ECLASS 10.0.1 | 27279090 |
| ECLASS 9.0 | 27279090 |
| ECLASS 8.0 | 27279090 |
| ECLASS 5.1 | 27279290 |
| ETIM 9.0 | EC003015 |
| ETIM 8.0 | EC003015 |
| ETIM 7.0 | EC003015 |
| ETIM 6.0 | EC003015 |
| ETIM 5.0 | EC003015 |
| UNSPSC 12.1 | 31251501 |
