Optocoupler VAZ-PLC-OSC-120UC/48DC/100/SEN
Brand: Pepperl+Fuchs
Code: VAZ-PLC-OSC-120UC/48DC/100/SEN
Optocoupler to convert 120 V inputs to 24 VDC
Datasheet excerpt: Technical data of VAZ-PLC-OSC-120UC/48DC/100/SEN
| Product Description |
|---|
| Optocoupler to convert 120 V inputs to 24 VDC |
| General specifications | ||
|---|---|---|
| Description | Optocoupler to convert 120 V inputs to 24 VDC | |
| Input | ||
| Voltage | 96... 132 V AC / 88... 121 V DC | |
| Input current | 3.5 mA | |
| Signal delay | 6 ms | |
| Signal frequency | 10 Hz | |
| Output | ||
| Current limit | 100 mA | |
| Current | approx. 0 mA | |
| Voltage | 3... 48 V DC | |
| Voltage drop | ≤ 1 V | |
| Mechanical specifications | ||
| Degree of protection | IP20 | |
| Connection | Terminals | |
Classifications
| System | Classcode |
|---|---|
| ECLASS 13.0 | 27242692 |
| ECLASS 12.0 | 27242692 |
| ECLASS 11.0 | 27242692 |
| ECLASS 10.0.1 | 27242692 |
| ECLASS 9.0 | 27242692 |
| ECLASS 8.0 | 27279212 |
| ECLASS 5.1 | 27279212 |
| ETIM 9.0 | EC003015 |
| ETIM 8.0 | EC003015 |
| ETIM 7.0 | EC003015 |
| ETIM 6.0 | EC003015 |
| ETIM 5.0 | EC003015 |
| UNSPSC 12.1 | 39121535 |
